Canopy LED Light Fixture

CP01 is multiple installations canopy light (Gas Station Light), comes with superb efficacy up to 150lm/w. Ideal lighting solution for safer and more appealing gas stations and low bay general lighting.

Multi-angle Display

Choose a 120°, 90° or 60° lens and Aluminum Reflectors are available as accessories.

60°

90°

120°

Can Be Equipped With Sensors

Get more energy saving with a smart Microwave Motion Sensor

Mounting Options

Recessed Mounting and Surface Mounting are available.

Mounting Options

Adjustable bracket for surface mounting and Recessed Mounting

Detail Parameters

Series CP01-Series
Power 75W,100W,120W,150W
Efficacy 150LM/W,130LM/W
Input Voltage 100-277VAC,50/60 Hz
Power Factor >0.9
Surge Protection 6KV Line-Line,6KV Line-Earth
Control 1-10V, DALI2
IP Rating IP66
IK Rating IK07
CCT 6500K,5700K,5000K,4000K,3000K
CRI CRI>70 standard CRI>80 optional
Operating Temperature -30°C — +45°C
Beam Angle 60,90,120 Angle
Mounting Option Spring Mount,Ceiling Mount,Bracket Mount,Embedded Installation
Control Protocol(s) 1-10V,DALI2(Optional)
Warranty 5 Years Warranty
